    Features:

    • Microprocessor-controlled ESD safe soldering station.
    • Closed loop control of temperature for precision soldering.
    • Designed with touch panel control and large digital display.
    • Compatible with Lead free applications.
    • Designed for efficiency.Replacement of tips with easy slip in/out method.
    • Compound tip allows excellent thermal recovery and immediate sensor response.
    • Wide selection of solder iron tips available for different soldering requirements.(Sold separately)
    • With the following added user friendly and safety features and functions:

    a) Auto sleep and wake up function.

    b) Digital offset function.

    c) Programmable sleep timer.

    d) System-lock out feature.

    e) Quick jump to favorite settings.

    f) Switch of temp display between Centigrade and Fahrenheit scale.

    SPECIFICATIONS
     POWER INPUT:  available in 110V / 220V
    WEIGHT: 2.5 Kg
    MAIN STATION DIMENSION:  115 x 155 x 90 mm
    SOLDERING IRON
    POWER CONSUMPTION:  70W
    OUTPUT VOLTAGE:  24V
     TEMPERATURE RANGE:  200°C- 480°C
    HEATING ELEMENT:  Ceramic heater
    TIP TO GROUND RESISTANCE:  Below 2 Ω
    TIP TO GROUND POTENTIAL:  Below 2mV



    AOYUE Int 2930  Package Content
    1 unit  Int2930 Main Station
    1 pc.  B034 Soldering Iron
    1 pc.  2660B Soldering Iron Stand
    1 pc.  Power Cord
    1 pc.  Instruction Manual
